FEATURES OF CONSTRUCTION BAR BENDING MACHINES

• Hour Meter: Innomac is introducing Hour meter for the first time in cutting and bending machinery. This helps P&M team to monitor machine utilization and plan scheduled maintenance.
• 4 Pre-set Angles: The machine is supplied with 4 preset angles (30, 45, 90, 180)
• PLC control system: Machine is controlled by a PLC instead of traditional relay system for trouble free operation.
• PLC panel placed on operator side for ease of serviceability.
• Maintenance free Electrical Braking system.
• Imported fully enclosed IP55 foot pedal.
• Moly Grease filled planetary gear box – Lubricated for life.
• Utility tray: Machine door encompasses a tray which can be highly useful for operator to store drawings and other ready reference documents.
• Rigid sliding block with V-guide provides more ruggedness.
• Completely powder coated machine body for better protection and aesthetics.
• All pins and bushes with Electro nickel plating for better protection.
• Rigid and easily accessible Grouting legs for easy grouting and better machine rigidity.
• Wider lifting lugs for ease of operation.
