INNOMAC PASSENGER CUM MATERIAL HOIST

INNOMAC PASSENGER CUM
MATERIAL HOIST

INNOMAC Passenger cum materials hoist, model: IPM-200 is an 100% make in India concept product designed to lift 2000 kg . It is the most robust, efficient, reliable and Safest PM Hoist for construction sites for various construction mounting applications and construction activities.
INNOMAC Hoists are designed with FEA Compliant parts and assemblies to meet design robustness and reliability need of the equipment. The CNC Punching, bending ,CO welding operations in the specific dies and fixtures makes the unit perfect and produce reduced noise and vibrations.
The Modern electric system of the LED Lighting, fan, the smooth operations of the machine with VFD drive, sliding door system, joystick operations with the option of overload cut off, floor selector and emergency switch panel make the operator more comfortable and confident to use the machine and remain fatigue free.

ERGONOMIC DESIGN

INNOMAC Hoists are designed with FEA Compliant parts and assemblies to meet design robustness and reliability need of the equipment. The CNC Punching, bending ,CO welding operations in the specific dies and fixtures makes the unit perfect and produce reduced noise and vibrations.

The Modern electric system of the LED Lighting, fan, the smooth operations of the machine with VFD drive, sliding door system, joystick operations with the option of overload cut off, floor selector and emergency switch panel make the operator more comfortable and confident to use the machine and remain fatigue free.

INNOMAC BMU

INNOMAC BMU
(Building Maintenance Unit)

The Equipment is called as building maintenance
unit / facade access equipment / window
cleaning equipment / window washing unit.

A building maintenance unit (BMU) is an automatic, remote – controlled, or mechanical device, usually suspended from the roof, which moves systematically over some surface of a structure while carrying human window washers or mechanical robots to maintain or clean the covered surfaces. BMUs are almost always positioned over the exterior of a structure, but can also be used on interior surfaces such as large ceilings (e.g. in stadiums or train stations) or atrium walls.

Innomac Column Mounted Hoist

INNOMAC COLUMN MOUNT HOIST

INNOMAC Designs, Manufacture and Supply the range of Innomac Column Mount Hoist

Our Machines are highly efficient, safe and durable with advanced features. Quality stands first for

INNOMAC and our machines reflect it in every aspect.

Specification

INNOMAC SCAFFOLDING LIFT

INNOMAC SCAFFOLDING LIFT

INNOMAC Designs, Manufacture and Supply the range of Scaffolding lift

Our Machines are highly efficient, safe and durable with advanced features. Quality stands first for

INNOMAC and our machines reflect it in every aspect.

SCAFFOLD LIFTING EQUIPMENT

INNOMAC SCRAP STARIGHTEING MACHINE

INNOMAC BAR SCRAP STARIGHTEING MACHINE

INNOMAC Designs, Manufacture and supply the range of Scrap Bar Straightening Machine

Our machines are highly efficient, Safe and durable with advanced features. Quality stands first for

INNOMAC and our machines reflect it in every aspect.

UNIQUE FEATURES OF INNOMAC SCRAP STRIGHTEING MACHINE - ISSM-12

  • In-Built Toolbox
  • Hour Meter / for Productivity & Maintenance Schedule.
  • Wheels for Easy Mobility
  • Semi-Automatic Cutting Machine.
  • Siemens DOL Starter for highest reliability.
  • Planetary Gear System in the Gear Box for higher Reliability & Efficiency.

Machine Specification

SPIRAL BAR BENDING MACHINE

Spiral Bar Bending Machine

INNOMAC Designs, Manufacture and supply the range of Rebar Spiral Bending Machines.

Our machines are highly efficient, Safe and durable with advanced features. Quality stands first for

INNOMAC and our machines reflect it in every aspect

Machine Specification

Capacity Chart

Stirrup Bar Bending Machine

Stirrup Bar Bending Machine

INNOMAC Designs, Manufacture and supply the range of Rebar Stirrup Bending Machines.

Our machines are highly efficient, Safe and durable with advanced features. Quality stands first for

INNOMAC and our machines reflect it in every aspect.

Machine Specification

Capacity Chart

INNOMAC REBAR MATERIAL HOIST

INNOMAC REBAR MATERIAL HOIST

INNOMAC Rebar Material Hoist is a Rugged designed system for easy vertical material movement in construction sites offering best in class features, reliability and safety. The drive system of the machine is with latest technology In-line gear box and energy efficient reliable IE-2 Brake Motor.

The built-in brake system in the motor provides safety by self-locking during power failure, the Machine also has a mechanical safety lock in case of any rope slips / rope damage.

INNOMAC MATERIAL HOIST

INNOMAC MATERIAL HOIST

It’s Truly multifunctional

Build More.!
Build Fast..!!
Build Safe…!!!

MODELS: IMH1000 & IMH1500

(IN COMPLIANCE WITH IS12466:2012)

SAFETY FEATURES

  • Emergency cut off switch
  • Power fail safe brake motor
  • Mechanical free fall arrester lock
  • Upper limit switch
  • Lower limit switch
  • Fully guarded drive unit

INNOMAC Material Hoist is a Rugged designed system for easy vertical material movement in construction sites offering
best in class features, reliability and safety. The drive system of the machine is with latest technology In-line gear box and
energy efficient reliable S-4 Duty Brake Motor. The built-in brake system in the motor provides safety by self-locking during power
failure, the Machine also has a mechanical safety lock in case of any rope slips / rope damage.

STANDARD ACCESSORIES :
Mechanical Safety Lock:
This is a free fall protection system which automatically latches the material cage to the mast in case of any rope failure.
Hour Meter:
INNOMAC has introduced Hour meter in material hoist which can help P & M team to monitor the machine utilization and plan scheduled maintenance activities.
Upper and Lower Limit Switch:
All models come with safety top and bottom limit switch as a standard feature which auto cuts off the power in case of the operator missing to switch it off in time.
Emergency Shut-Off Switch:
INNOMAC provides dual emergency Switches, one on the control panel and another on the pendant as a standard safety feature which can be used in case of an emergency to stop the machine immediately.
Pendant Operation System:
This helps the operator to control the machine easily moving around it.
Heavy Duty Gear Box:
Planetary Gear Box is directly coupled with the brake motor and thus eliminates conventional belts & chains, hence is low Maintenance Technology. hence is low Maintenance Technology.
Bigger Cage:
INNOMAC Provides the largest cage among any brands with the size of 1250 x 830 x 610 mm this helps to carry big volume Materials, concrete blocks and other items up to the rated net capacity of the equipment.
Masts:
The Masts are Designed for Highest Reliability Factor, made on Necessary jigs and fixtures to ensure Interchangeability and Perfection of Fabrication.
Wall Ties:
This eliminates the scaffolding and other arrangement costs for installing the masts. The wall tiles are designed for fixing at 6-meter intervals.
Jib Crane Unit (Optional) :
Special attachment with manual winch to ensure Safe & Easy erection of Mast structure/Tower.
Wall tie Installation Platform ( Optional ):
INNOMAC has introduced Wall Tie installation platform for the first time in India for Material hoists

INNOMAC CONSTRUCTION LIFT

INNOMAC CONSTRUCTION LIFT

Innomac Construction Lifts are robust in design having best in the segment features like high Operating
speed, 360° Rotation, Safety limit switch, rigid drive system and etc.

The structure and major components are designed with FEA to meet higher reliability of the equipment.

STANDARD ACCESSORIES :

IE2 Brake Motors: Innomac is providing rugged made-in-India and energy efficient IE-2 motors for longer life and higher energy efficiency. The electro-mechanical built-in brake systems ensures safety during power failures.
Robust Gear Box: This machine comes with a heavy-duty speed reduction gear box directly coupled to the rope drum, thus eliminating any belt drives.
1.6 metre long Boom: This equipment provides a very long boom of 1.6 metre with 500 kg capacity with a very compact footprint which is best in its segment.
Safety limit switch: All models comes with a safety top limit switch as a standard option with auto motor cut-off, in case of operator missing to switching it off on time.

Counter weight tray: The machine can be attached to two rugged counter weigh trays which are specially designed to take 4” or 6” concrete blocks.
Counterweight bucket: Apart from the machine counterweight system we also provide a boom counterweight system to balance the weight of the boom.
Pendent operation control: Machine is controlled by a relay based control panel which auto cuts off in case of overload, over traverse. The operator buttons are mounted through the remote pendent for easy of operation.
Tool Box: Innomac has introduced tool box in mini-lift for the first time in the industry, which can be used to store tools or any ready spare parts.
Winch Motor Cover: The machine comes with fully guarded motor and gear box which provides safety and protection.
FEA complaint: The machine is tested and verified both practically and by FEA software to get the best performance of the machine.

OPTIONAL ACCESSORIES :

Brick handling tray : Specially designed, mesh covered tray for lifting concrete blocks in construction sites.
Sand/Concrete tray : Specially designed robust structure concrete tray with no leakage.
Load cell : This acts as a overload protection when the load crosses 500KG.
Counter Weight : Specially designed high grade concrete counter weight with steel enclosure and handle for longer life.
